The innovative FOV of Smart Plus provides an arch-shaped volume, which shows a wider view of dentition compared to other devices with the same FOV.
One scan with the Smart Plus gives you not just a CT image, but also an Auto Pano image. This means, patients who require both images do not need to undergo two x-ray scans. Also, CT and Auto Pano images are displayed within one viewer.
The innovative FOV of the Smart Plus provides an arch-shaped volume, which shows a wider view of the dentition compared to other devices of the same FOV. When a tooth is lying on its side, there is a high possibility that the tooth will be cut out of the image. The “arch-shaped volume” eliminates this possibility and shows the hidden dentition area.
Scan type cephalometric offers two image sizes, LAT and FULL LAT, you can choose one of them based on the purposes of your diagnostic needs. Provide specialized high quality images to suit full lateral gives 30% larger images and the occipital orthodontics and maxillofacial surgeries’ area of the patient for comprehensive diagnosis. (optional)
Function | CT (with Auto Pano) + Pano + Ceph + Model Scan |
Focal Spot | 0.5 mm (IEC 60336) |
CT FOV Size | 5x5 cm / 10x8.5 cm (Anatomical 12x9 cm) / 10x7 cm |
Voxel Size | 0.08 mm / 0.12 mm / 0.2 mm / 0.3 mm |
CT Scan Time | 18 sec |
Pano Scan Time | 14.1 sec / 7 sec |
Ceph Scan Time | 1.9 sec / 3.9 sec |
Gray Scale | 14 bit |
Tube Voltage | 60 ~ 99 kV |
Current | 4 ~ 16 mA |
Weight with Ceph unit | 357.1 lbs |
